Biofilters

Biofilters rely on biological processes, carried out by microorganisms such as bacteria, fungi, and protozoa, to break down and remove harmful, polluting, or odorous compounds from air streams. Typical pollutants treated in biofilters include volatile organic compounds (VOCs), hydrogen sulfide (H₂S), ammonia (NH₃), and various odour-causing compounds. These substances are biologically converted into harmless end products such as carbon dioxide, water, mineral salts, and biomass.

Biofilters are often a low-maintenance and cost-effective air treatment solution, particularly for applications involving large air volumes and relatively low pollutant concentrations.

how does it work?

how constructed?

How does a biofilter work?

A biofilter consists of a bed of organic material, commonly a mixture of wood chips, bark, compost, peat, or other biologically active media. This material provides a suitable substrate on which microorganisms can colonize and grow.

To maintain biological activity, the filter media must remain sufficiently moist. This can be achieved either through the humidity present in the incoming air stream or by dedicated irrigation or humidification systems.

The contaminated air is passed through the biofilter bed, where pollutants are absorbed into the moist biofilm surrounding the microorganisms. These microorganisms use the pollutants as a source of energy and nutrients, degrading them into harmless compounds. Over time, microbial populations naturally adapt to the specific pollutants present in the air stream, increasing treatment efficiency.

How is a typical biofilter constructed?

A typical biofilter installation consists of the following components:

1. Housing or containment structure

A housing is constructed to contain the biofilter media. For smaller airflow rates, this may be a polymer enclosure or a repurposed container. Larger installations are commonly built from reinforced concrete.

2. Air distribution system

One or more air inlets are installed at the bottom of the biofilter. Ducting and distribution plenums ensure that incoming air is evenly distributed across the entire filter surface, preventing channeling and maintaining uniform treatment performance.

3. Support floor and media bed

A perforated support floor or grid is installed above the air distribution plenum. This structure supports the biofilter media while allowing air to flow upward through the bed.

4. Exhaust section

The top of the biofilter may be left open to allow treated air to be discharged directly to the atmosphere. Alternatively, a covered design with an outlet connection can be used when treated air must be conveyed to downstream equipment or discharged at a specific location.

Where is a biofilter used?

For effective operation, environmental conditions within the biofilter must remain favorable for microbial activity.

Key operating parameters include:

Temperature: typically between 15°C and 35°C
Relative humidity: sufficiently high to keep the media moist
Nutrient availability: adequate to sustain microbial growth
Air distribution: uniform throughout the filter bed

Where necessary, upstream conditioning equipment such as humidifiers, cooling systems, or heaters may be installed to ensure suitable inlet conditions.

Biofilters are particularly suitable when:

Pollutant concentrations are relatively low and stable.

Sudden peaks or excessively high pollutant loads can disrupt the biological balance within the filter media and reduce treatment efficiency. Conversely, a minimum pollutant loading is required to sustain the microbial population.

Large air volumes must be treated.

Biofilters scale very well and are often one of the most economical solutions for treating large air flows. Unlike many alternative technologies, construction costs remain relatively low even for high-capacity systems.

The pollutants are biodegradable.

Compounds such as hydrogen sulfide (H₂S), ammonia (NH₃), alcohols, aldehydes, ketones, and many odorous VOCs are readily degraded by microorganisms. In contrast, acid gases such as hydrogen chloride (HCl) and hydrogen fluoride (HF), as well as many halogenated VOCs, are generally unsuitable for biological treatment and require alternative technologies.

Typical industrial applications

Biofilters are widely used in industries where odour control or treatment of biodegradable gaseous pollutants is required, including:

Textile manufacturing industry

Removal of specific biodegradable solvent vapours and process emissions.

Food and animal feed industry

Treatment of odorous compounds generated during production, storage, and processing operations.

Anaerobic digestion and biogas plants

Removal of hydrogen sulfide (H₂S), ammonia (NH₃), and other odorous compounds from digester off-gases and process ventilation streams.

Composting and waste treatment facilities

Treatment of odorous process air generated during biological waste processing.

Frequently asked questions about biofilters

Are biofilters environmentally friendly?

Yes.

Biofilters are widely regarded as one of the most environmentally friendly air treatment technologies available. They rely on natural biological processes, consume relatively little energy, and typically require few or no treatment chemicals. In addition, the filter media is often derived from renewable organic materials and can frequently be recycled or composted at the end of its service life.

Can a biofilter be combined with other air pollution control systems?

Yes.

Biofilters are frequently combined with other treatment technologies to achieve the required removal efficiency. A common configuration is a chemical scrubber followed by a biofilter. The scrubber removes acid gases, alkaline compounds, or other substances that could inhibit biological activity, while also humidifying the air stream. The biofilter then efficiently removes residual odours and biodegradable pollutants.

Can a biofilter handle fluctuating pollutant concentrations?

Biofilters can generally accommodate minor fluctuations in pollutant concentration and airflow. However, large or prolonged peaks in pollutant load can reduce treatment efficiency, as the microorganisms may not be able to adapt quickly enough. Likewise, extended periods without pollutants can negatively affect the microbial population because their food source is removed. For optimal performance, biofilters operate best under relatively stable conditions.

Does a biofilter produce waste?

Biofilters generate very little waste. Over time, the filter media will need to be replaced, but since the media is typically organic and non-hazardous, disposal or recycling is generally straightforward and cost-effective. In some cases, spent media can even be composted or otherwise beneficially reused, depending on local regulations.

How long does biofilter media last?

The lifespan of biofilter media depends on the operating conditions, pollutant load, and media composition. Under favourable conditions, filter media can last between 3 and 10 years. In more demanding applications with high pollutant loads, partial or complete media replacement may be required more frequently.

How do I know whether a biofilter is a suitable solution for me?

Biofilters are particularly well suited for applications with a continuous airflow and relatively low, stable concentrations of biodegradable pollutants. Typical applications include process ventilation and extraction systems in the food, feed, waste processing, wastewater treatment, and biogas industries.
